• SVCOFFROAD 1.75IN Front Leveling Spacer Included
• SVCOFFROAD Aluminum Steering Tierod Included
• SVCOFFROAD Steering Stiffener Included
• Run 35in Tires
• Made In The USA
• Save 5% Buying As Package

NOTE: Some trimming in the fender well is required to clear 35in tires and best ride results will come with Ford ForScan Live Valve ride height calibration.  Please contact us if you aren't familiar with this process.  Its very easy to perform and is a great tool to have for any Ford 2019+ Raptor owner of all variants.

• Lifts Front of Truck 1.75" To Fit 35in Tires
• Levels Truck
• Fits On Factory Fox Shock
• Billet Aluminum

• Made In The USA

Note:  A live valve ride height reset via ForScan is highly recommended.  If you don't know what that is, please contact us for how to perform and get access to ForScan.  Its a very simple process and great tool to have for any 2019+ Ford Raptor owner of al Models

NOTE: SOME FENDER WELL TRIMMING IS STIL REQUIRED TO CLEAR 35IN TIRES.

• Made In The U.S.A.
• Grade 8 Hardware
• 4130 Nickel Plated Machined Clevis
• Hard Anodized Aluminum Rod
• Inner Steering Strengthener Included

• One Set of Upper Control Arms and Perch Leveling Collars
• CNC Billet Aluminum
• Camber / Caster Adjustable On The Truck
• Billet Dirt Cap For Longer Uniball Life
• FK Bearings and Rodends
• Hard Anodized
• Levels The Truck
• Increase Performance
• Run Larger Tires

• CNC Billet Aluminum
• Camber / Caster Adjustable On The Truck
• Billet Dirt Cap For Longer Uniball Life
• FK Bearings and Rodends
• Hard Anodized
• Compatable With Fox and King Factory Coilovers.

OVERVIEW:
Our new 2019 Ford Ranger Billet Upper Control Arms are designed to withstand the harshest of terrain, all the while giving you the ability to increase your ride height of the vehicle with the use of an aftermarket coilover.

SVC Offroad UCA's increase the strength of your Rangers suspension to give  you a locked down feel both on and offroad.  They are both camber and caster adjustable while on the vehicle with the use of our dual adjuster system, and utilize FK Bearings and Rod Ends.  We took extra steps to hard anodize the arms for greater strength plus add billet dust caps for increase center bearing life.

Upgrading your Upper Control Arms is one of the most effective and best bang for your buck mod you can do...

• Direct Replacement of Factory Spring Perch
• Levels Truck /With optional .5" perch addition included
• Fits On Factory Shock
• Billet Aluminum
• Hard Anodized
• Made In The USA
• Allows You To Run Larger Tire Size
• Does not fit the Tremor Ranger

INSTALL INSTRUCTIONS: https://docs.google.com/document/d/1cGRVbWgs74g2WbFGtbxytnFwxx7UQp6qWMbHt0bKUMs/edit

OVERVIEW:

Tired of the rear high stink bug look?  SVC Offroad has and easy fix.  We developed a lower spring perch collar leveling system to work with your existing Gen 5 Ford Ranger shock.  By simply replacing the lower spring collar with our new larger billet unit, you will be able to level the front of your truck and fit up to 33" tires (note, depending on the tire trimming may be required).

The install is easy and straight forward and totally transforms the look and feel of your truck.

• Made In The U.S.A.
• Hard Anodized Aluminum Rod

 RANGER TIE-ROD INVENTORY BLOW OUT SALE GOING ON NOW!!!  SAVE $113.00

SVC Offroad tie rods are made right here in the USA! Installing these on your 2019 Ford Ranger will allow for tighter steering, better looks and overall better performance both on and off-road.

• Body - 2.0” Impact extruded and CNC machined 6061-T6 clear anodized aluminum one-piece body resists rust over time
• Body Plating - Clear-anodized for a durable finish
• Reservoir - Internal IFP mono-tube reservoir design
• Components - Black-anodized, CNC-machined 6061-T6 billet aluminum
• Shaft - 5/8" hard chrome plated heat-treated alloy steel
• Piston - Race-developed high-flow piston design
• Valving - Application specific valving to maximize performance
• Seals - Redundant sealing pack system main seal, wiper seal, scraper seal
• Oil - JM92 Advanced Suspension Fluid for improved performance at variable temperatures
• Bearing - Large diameter, heavy-duty spherical
• Adjustments - Ride height preload ring
• Travel (in) - 4.470
• Compressed (in) - 16.030
• Extended (in) - 20.500
• Top Mount - OEM
• Bottom Mount - Eyelet

OVERVIEW:

• Body - 2.0” Impact extruded and CNC machined 6061-T6 clear anodized aluminum one-piece body resists rust over time
• Body Plating - Clear-anodized for a durable finish
• Reservoir - Internal IFP mono-tube reservoir design
• Components - Black-anodized, CNC-machined 6061-T6 billet aluminum
• Shaft - 5/8" hard chrome plated heat-treated alloy steel
• Piston - Race-developed high-flow piston design
• Valving - Application specific valving to maximize performance
• Seals - Redundant sealing pack system main seal, wiper seal, scraper seal
• Oil - JM92 Advanced Suspension Fluid for improved performance at variable temperatures
• Bushings - Quiet nitrile rubber allows for increased suspension articulation
• Travel (in) - 9.690
• Compressed (in) - 16.303
• Extended (in) - 25.993
• Top Mount - Eyelet
• Bottom Mount - Eyelet

OVERVIEW:

Before any of our shocks reach production, they've had to stand the test of time and live up to incredible abuse by the fastest athletes in racing. We push the boundaries to give you that same precise control and race-proven performance you can feel. Our bolt-on Factory Race Series Coil-over Reservoir shocks provide improved damping in any terrain.

Coil-over shocks provide suspension damping and suspend the weight of the vehicle. The integrated coil spring can be adjusted for preload and ride height and come pre-set to level your vehicle right out of the box. Experience for yourself the incredible performance and precise control that Factory Series Coil-over Reservoir shocks deliver.

Factory Race Series 2.5 Reservoir smooth body shocks give you enhanced ride quality and the control you need when heading off the pavement. They take their design from our Off-Road race shocks, so they've been thoroughly perfected in brutal conditions that you will probably never see. Our athletes push the boundaries in competition to develop race-proven performance you can bolt onto your Truck or SUV.

External reservoir allows for increase oil and nitrogen capacity while delivering striking race look. Applications are available to fit most stock and lifted Trucks and SUVs. Our complete line of bolt-on, Factory Series shocks provide improved damping in any terrain. Experience for yourself the incredible performance and precise control that Factory Race Series 2.5 Reservoir shocks deliver.

Save 5% Off Retail

SVCOFFROAD BILLET UPPER CONTROL ARMS

• CNC Billet Aluminum
• Camber / Caster Adjustable On The Truck
• Billet Dirt Cap For Longer Uniball Life
• FK Bearings and Rod-Ends
• Hard Anodized
• Compatible With Fox and King Factory Coilovers.

SVCOFFROAD MACHINED ALUMINUM STEERING TIE-RODS

• Sharper Steering
• Greater Strength
• Machined Bearing Cup With Integrated Pivot Bolt
• Hard Anodized

FOX RACING SHOX FACTORY RACE SERIES 2.5 DSC (DUAL SPEED COMPRESSION) COIL-OVERS

Before any of our shocks reach production, they've had to stand the test of time and live up to incredible abuse by the fastest athletes in racing. We push the boundaries to give you that same precise control and race-proven performance you can feel. Our bolt-on Factory Race Series Coil-over Reservoir shocks provide improved damping in any terrain.

Coil-over shocks provide suspension damping and suspend the weight of the vehicle. The integrated coil spring can be adjusted for preload and ride height and come pre-set to level your vehicle right out of the box. Experience for yourself the incredible performance and precise control that Factory Series Coil-over Reservoir shocks deliver.

FOX RACING SHOX FACTORY RACE SERIES 2.5 DSC (DUAL SPEED COMPRESSION) SHOCKS

Factory Race Series 2.5 Reservoir smooth body shocks give you enhanced ride quality and the control you need when heading off the pavement. They take their design from our Off-Road race shocks, so they've been thoroughly perfected in brutal conditions that you will probably never see. Our athletes push the boundaries in competition to develop race-proven performance you can bolt onto your Truck or SUV.

External reservoir allows for increase oil and nitrogen capacity while delivering striking race look. Applications are available to fit most stock and lifted Trucks and SUVs. Our complete line of bolt-on, Factory Series shocks provide improved damping in any terrain. Experience for yourself the incredible performance and precise control that Factory Race Series 2.5 Reservoir shocks deliver.
